CCEWOOL® Stone Wool Batt

CCEWOOL® Stone Wool Batt is a high-performance semi-rigid stone wool insulation product designed for new construction and renovation of residential and commercial buildings. It is suitable for insulation systems in wood and steel frame walls, ceilings, floors, and attics. This stone wool batt features unique flexible edges that allow easy compression during installation, ensuring seamless filling of framing cavities while preventing over-compression, thus maintaining its excellent R-value performance.
Stone Wool Batt

CCEWOOL® Stone Wool Batt is a high-performance semi-rigid stone wool insulation product designed for new construction and renovation of residential and commercial buildings. It is suitable for insulation systems in wood and steel frame walls, ceilings, floors, and attics. This stone wool batt features unique flexible edges that allow easy compression during installation, ensuring seamless filling of framing cavities while preventing over-compression, thus maintaining its excellent R-value performance.

The product is non-combustible and fire-resistant; even when directly exposed to flames, it will not emit toxic smoke or contribute to fire spread. In addition, it offers outstanding water resistance, moisture protection, and acoustic performance, making it an ideal choice for enhancing energy efficiency and creating a healthier indoor environment.

CCEWOOL® Stone Wool Batt combines high thermal efficiency, fire safety, and environmental sustainability, making it a premium solution widely applicable to various building needs—delivering safety, comfort, and sustainability.

Advantages

Excellent Soundproofing Performance, Creating a Quiet Space: The stone wool material offers outstanding noise reduction and sound absorption, effectively blocking noise transmission and creating a quieter, more efficient living and working environment.

Moisture and Mold Resistance, Long-lasting Protection for Building Health: The material has excellent water-resistant properties, does not rot, and does not promote mold or fungal growth, providing long-term, stable protection and health benefits for the building.

Exceptional Fire Resistance, Ensuring Safety and Reliability: Made from Class A non-combustible materials, it effectively controls the spread of fire and prevents flame propagation, providing a critical fire barrier and improving overall building safety.

Lightweight Design, Easy and Efficient Installation: The material is lightweight, easy to cut and handle, significantly simplifying the construction process, improving installation efficiency, and adapting to various building needs.

Features and Stone Wool

Features:
Breathability: Excellent vapor permeability helps wall systems stay dry and prevents condensation and moisture accumulation.

Fire protection: Non-combustible with a high melting point, providing reliable fire barriers in case of fire.

Environmentally sustainable: Manufactured from natural and recycled materials, free of CFCs and HCFCs, reducing environmental impact.

Moisture resistance: Low hygroscopicity effectively resists moisture damage and ensures long-term stability.

Stable R-value: Maintains superior thermal resistance throughout its service life, improving energy efficiency and reducing consumption.

Dimensional stability: Retains shape and insulation performance even in high humidity or high temperature environments.

Acoustic performance: Excellent sound absorption significantly reduces noise transmission, improving indoor acoustics.

Stone Wool:
Insulation for exterior walls in wood and steel frame structures;
Insulation and soundproofing for exposed floors and crawl spaces;
Thermal insulation for attic and ceiling systems.

Technical Parameters

CCEWOOL® Stone Wool Batt

Density

> 2 lb/ft³ (>32 kg/m³)

Dimensions

Wood Stud 16" (406 mm) on center: 15.25" x 47" (387 mm x 1194 mm)

Wood Stud 24" (610 mm) on center: 23" x 47" (584 mm x 1194 mm)

Steel Stud 16" (406 mm) on center: 16.25" x 48" (413 mm x 1219 mm)

Steel Stud 24" (610 mm) on center: 24.25" x 48" (616 mm x 1219 mm)

Reaction to fire

Class A Non-Combustible

Thermal resistance

Varied from R-10-R38

R 14 (RSI 2.47) - 3.5" thick (89 mm) R 10 (RSI 1.76) - 2.5" thick (64 mm)

R 22 (RSI 3.87) - 5.5" thick (140 mm) R 14 (RSI 2.47) - 3.5" thick (89 mm)

R 24 (RSI 4.23) - 5.5" thick (140 mm) R 22.5 (RSI 3.96) - 6" thick (152 mm)

R 28 (RSI 4.93) - 7.25" thick (184 mm) R 24 (RSI 4.23) - 6" thick (152 mm)

R 32 (RSI 5.64) - 8" thick (203 mm)

Product Range

R-value

Thickness (inch)

Width (inch)

Length (inch)

13

3.5

15.25

47

13

3.5

23

47

15

3.5

15.25

47

15

5.5

23

47

21

5.5

15.25

47

21

5.5

23

47

23

5.5

15.25

47

23

5.5

23

47

30

7.25

15.25

47

30

7.25

23

47
